Descripción
- 6.5-inch LED screen with concise and friendly-use interface.
- Built-in microprocessor chip has Intelligent functions such as automatic calibration, ATC, data storage, clock display, USB output, function settings, wireless printing, and self-diagnosis information, etc.
- It supports wireless bluetooth printing. Real-time data transfer to mobile phone via bluetooth is optional.
- Smart electrode status display to ensure accurate use.
- Omron long lasting and light touch key can be used more than 100,000 times.
- Can store 1000 sets of test data, which can be saved and transferred to USB memory stick and opened with Excel.
- Adopt advanced conductivity measurement technology, with conductivity electrode (K=1), it can meet measuring accuracy requirement for range of 0.5μS/cm ~ 200mS/cm.
- Can switch among conductivity, TDS, salinity and resistivity. Multinomial calculation for TDS and salinity to ensure the conversion precision of the full scale.
- Auto recognition of 8 conductivity standard solution with 2 kinds of options: Europe & USA, and China.
Especificaciones técnicas
Modelo | YR01837 | |
Cond.
|
Rango de medición
|
Conductividad: |
(0.00~20.00)μS/cm, (20.0~200.0)μS/cm | ||
(200~2000)μS/cm, (2.00~20.00)mS/cm | ||
(20,0~200,0)mS/cm, | ||
(200~2000)mS/cm (K=10) | ||
TDS:(0 ~ 100)g/L | ||
Salinidad:(0 ~ 100)ppt | ||
Resistividad:(0 ~ 100)MΩ-cm | ||
Resolución | 0,01/0,1/1μS/cm; 0,01/0,1mS/cm | |
Precisión | Electrodo: ±0,5% FS, Medidor: ±0,8% FS | |
Compensación temp. | (0 ~ 50)ºC, auto | |
Constante del electrodo | 0,1 / 1 / 10 cm-1 | |
Temp. de referencia | 25ºC,20ºC,18ºC | |
Temp.
|
Rango de medición | (0 ~ 100)ºC |
Resolución | 0,1ºC | |
Precisión | 5 ~ 60ºC:±0,4ºC Otros: ±0,8ºC | |
Otros
|
Mostrar | Pantalla LED de 6,5 pulgadas |
Almacenamiento de datos | 1000 juegos | |
Potencia | 12V/1A | |
Salida | USB, RS232, Bluetooth | |
Temp. ambiente | 5 ~ 35 ºC | |
Humedad ambiente | ≤85% | |
Grado IP | IP54 | |
Dimensiones/N.A. | 240×170×70mm/600g | |
Tamaño del envío/G.W. | 470x430x85mm/2,6kg |
